The ball at the top of the downrod allows the fan to face six directions, confirm a
direction before placing the ball onto the mounting bracket. As shown in the diagram
below.
Tighten the two downrod set screws to make sure the fan run stably. Then, install
downrod (ball part) into
mounting bracket opening that already securely fastened to
a structural ceiling member. The tab opposite of the
mounting bracket opening should
fit in slot on ball.
ATTENTION: MAKE SURE ALL WIRES ARE PROPER CONNECTED.
9.
8.
Mounting Bracket
