Vento FINO - CODE SWITCH SETTING; DIP Code Setting Procedure

RECEIVER
ANTENNA
9V BATTERY
12
3
4
ON DIP
DIP SWITCH
To open battery cover slide down the cover
according to the arrow direction.
V. CODE SWITCH SETTING
1.
2.
3.
4.
5.
6.
These DIP code can be pushed upward and downward to change the setting.
Both of these remote control components (receiver and transmitter) have a set of four
switches that need to have the same settings. (The total combination becomes 16
frequency codes).
The setting determines the frequency that will be used to control the ceiling fan.
Otherwise, the ceiling fan will not operate.
Once the setting has been made, slide down the back cover of transmitter to the arrow
direction. Install a 9 Volt battery.
Now the remote control receiver module is ready for installation up at the ceiling fan
of mounting bracket.
Select different combinations of dip switches to prevent mis-operation due to other
remote control fans.
