FIGURE 2 - DECK PARTS
PARTS
E-4
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....83.0031 .......83.0031 ........Idler Pulley ..................... 2
2.....90.0614 .......90.0614 ........3/8-16 x 1-3/4 Bolt .................2
3.....94.06 ........94.06..........3/8USSFlat Washer ...............1
4.....99.A12NF ......99.A12NF .......3/4SAELocknut ..................3
5.....95.12 ........95.12..........3/4SAEFlatwasher ................3
6.....70.8040 .......70.8041 ........Spindle Pulley Kit .................3
7.....90.0636 .......90.0636 ........3/8-16 x 4-1/2 Bolt .................1
8.....50.0047 .......50.0047 ........Front Roller .................... 1
9.....50.0046 .......50.0046 ........Front Roller Spindle ................1
10....99.A06 ........99.A06 .........3/8-16 Locknut ...................2
11....03.0002 .......03.0002 ........Latch Pin 3/8 x 2” .................2
12....00.0123 .......00.0123 ........Keep Hands & Feet Away Decal..........3
13....90.0606 .......90.0606 ........3/8-16 x 3/4 Bolt ..................1
14....41.0020 .......41.0020 ........Spring ....................... 1
15....90.0608 .......90.0608 ........3/8-16 x 1 Bolt ...................2
16....95.06 ........95.06..........3/8SAEWasher (As required) ..........20
17....62.0889 .......62.0891 ........Side Discharge Chute ...............1
18....00.0122 .......00.0122 ........Decal - Thrown Object Hazard...........1
19....64.0602 .......64.0602 ........3/8x5/8x5/16 Bushing ..............3
20....99.SF06 .......99.SF06 ........3/8-16 Flange Nut ................. 19
21....90.0610 .......90.0610 ........3/8-16 x 1-1/4 Bolt.................12
22....55.0035 .......55.0035 ........Ball Bearing .................... 6
23....87.0178 .......87.0178 ........Housing ...................... 3
24....87.0179 .......87.0179 ........Spacer ....................... 3
25....29.GF0001 .....29.GF0001 .......1/4-28 Grease Fitting ...............3
26....70.8039 .......70.8039 ........Spindle Shaft Kit ..................3
27....70.8037 .......70.8037 ........Spindle Assembly Kit ...............3
28....79.0036 .......79.0038 ........LowLiftBlade ................... 3
.....79.0035 .......79.0037 ........High Lift Blade ...................3
.....79.0046 .................... Gator Blade .................... 3
29....64.0688 .......64.0688 ........Spindle Guard ................... 3
30....91.0810 .......91.0810 ........1/2-20 x 1-1/4 Bolt .................3
31....99.SF05 .......99.SF05 ........5/16-18 Flange Nut ................ 2
32....42.0385 .......42.0385 ........Idler Adjustment Rod ...............1
33....41.0048 .......41.0048 ........Spring ....................... 1
34....40.0238 .......40.0238 ........Idler Arm ...................... 1
35....99.SF0606......99.SF0606 .......3/8-16 x 3/4 Flange Bolt ..............4
36....64.0669 .......64.0669 ........Deck Carrier Slide .................2
37....81.B158 .......81.B180 ........Belt......................... 1
38....00.0062 .......00.0062 ........Decal - Shield Missing ...............1
39....notavailable .....notavailable ......Serial Number Plate ................1
40....62.0888 .......62.0890 ........Deck ........................ 1
40................62.0900 ........Offset Deck, HP720 ................1
41....00.0102 .......00.0102 ........Pinch Hazard Decal ................1
