FIGURE 4
SPINDLE ASSEMBLY
PARTS
E-8
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....81.B158 .......81.B180 ........Belt......................... 1
2.....99.A12NF ......99.A12NF .......3/4-16 Lock Nut .................. 3
3.....99.B0057-2 .....99.B0057-2 ......10ga.x3/4x1-1/4 Machine Washer .......3
4.....83.0051 .......83.0052 ........Spindle Pulley ................... 3
5.....85.B0080 ......85.B0080........Pulley Spacer ................... 3
6.....55.0057 .......55.0057 ........Ball Bearing, 2-sided Shield ............3
7.....90.0610 .......90.0610 ........3/8-16 x 1-1/4 Bolt.................12
8.....95.06 ........95.06..........3/8SAEFlat Washer ...............12
9.....99.SF06 .......99.SF06 ........3/8-16 Flange Nut .................12
10....29.GF0017 .....29.GF0017 .......Relief Fitting .................... 3
11....55.0035 .......55.0035 ........Ball Bearing, Single Shield.............3
12....87.0209-1 ......87.0209-1 .......Spindle Housing .................. 3
13....29.GF0001 .....29.GF0001 .......1/4-28 Grease Fitting ...............3
14....87.0209 .......87.0209 ........Spindle Assembly, Right Hand Thread.......3
15....87.0209-2 ......87.0209-2 .......Spindle Shaft, Right Hand Thread .........3
16....85.W0406 ......85.W0406 .......1/4x3/4Woodruff Key...............3
17....87.0210 .......87.0210 ........Spindle Flange Shield ...............3
18....79.0036 .......79.0038 ........LowLiftBlade ................... 3
.....79.0035 .......79.0037 ........High Lift Blade ...................3
.....79.0046 .................... Gator Blade .................... 3
19....64.0688 .......64.0688 ........Spindle Guard ...................3
20....91.0814 .......91.0814 ........1/2-20 x 1-3/4 Bolt .................3
21....99.B0091 ......99.B0091........Blade Washer ................... 3
22....85.B0082 ......85.B0082........Bushing, Spindle Shaft Spacer...........3
To Next Page
