FIGURE 3
DECK PARTS
PARTS
E-6
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....83.0031 .......83.0031 ........Idler Pulley ..................... 2
2.....90.0614 .......90.0614 ........3/8-16 x 1-3/4 Bolt .................2
3.....94.06 ........94.06..........3/8USSFlat Washer ...............1
4.....90.0636 .......90.0636 ........3/8-16 x 4-1/2 Bolt .................1
5.....50.0047 .......50.0047 ........Front Roller .................... 1
6.....50.0046 .......50.0046 ........Front Roller Spindle ................1
7.....99.A06........99.A06 .........3/8-16 Lock Nut .................. 3
8.....03.0002 .......03.0002 ........Latch Pin, 3/8 x 2” .................2
9.....00.0123 .......00.0123 ........Decal, Keep Hands & Feet Away .........3
10....90.0606 .......90.0606 ........3/8-16 x 3/4 Bolt ..................1
11....41.0020 .......41.0020 ........Spring ....................... 1
12....90.0608 .......90.0608 ........3/8-16 x 1 Bolt ...................2
13....95.06 ........95.06..........3/8SAEFlat Washer (as required) ........8
14....62.0889 .......62.0891 ........Side Discharge Chute ...............1
15....00.0122 .......00.0122 ........Decal, Thrown Object Hazard ...........1
16....64.0602 .......64.0602 ........3/8x5/8x5/16 Bushing ..............3
17....99.SF06 .......99.SF06 ........3/8-16 Flange Nut .................9
18....99.SF05 .......99.SF05 ........5/16-18 Flange Nut ................ 2
19....42.0385 .......42.0385 ........Idler Adjustment Rod ...............1
20....41.0048 .......41.0048 ........Spring ....................... 1
21....40.0238 .......40.0238 ........Idler Arm ...................... 1
22....99.SF0606......99.SF0606 .......3/8-16 x 3/4 Flange Bolt ..............4
23....64.0669 .......64.0669 ........Deck Carrier Slide .................2
24....00.0062 .......00.0062 ........Decal, Shield Missing ...............1
25....00.0102 .......00.0102 ........Decal, Danger - Pinching Hazard .........1
26....notavailable .....notavailable ......Decal, Serial Number Plate ............1
27....62.0888 .......62.0890 ........Deck, HM ..................... 1
.................62.0900 ........Offset Deck, HP720 ................1
