FIGURE 5
CARRIER FRAME PARTS
PARTS
E-10
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....60.0662 .......60.0676 ........Deck Shield .................... 1
1.................60.0758 ........Offset Deck Shield, HP720 ............1
2.....00.0189 .......00.0189 ........Ventrac Decal ...................1
3.....00.0192 .......00.0192 ........V-Decal ...................... 1
4.....62.0758 .......62.0764 ........Carrier Frame ................... 1
5.....99.SF06 .......99.SF06 ........3/8-16 Flange Nut .................7
6.....94.06 ........94.06..........3/8USSWasher ..................4
7.....90.0640 .......90.0640 ........3/8-16 x 5 Bolt ...................2
8.....64.0671 .......64.0671 ........Deck/Carrier Spacer ................2
9.....64.0682 .......64.0682 ........Deck Shield Spring.................1
10....95.05 ........95.05..........5/16 SAE Flat Washer ...............3
11....41.0021 .......41.0021 ........1/2ODx2-3/4 Compression Spring ........1
12....99.A05 ........99.A05 .........5/16-18 Locknut ..................1
13....90.0524 .......90.0524 ........5/16-18 x 3 Bolt ..................1
14....43.006 ........43.006 .........3/8-24 Spherical Rod End .............4
15....90.0610 .......90.0610 ........3/8-16 x 1-1/4 Bolt .................2
16....95.06 ........95.06..........3/8SAEWasher .................14
17....93.06 ........93.06..........3/8-24 Nut ..................... 4
18....99.J0640NFZ ....99.J0640NFZ .....Height Adjuster Rod ................2
19....90.0612 .......90.0612 ........3/8-16 x 1-1/2 Bolt .................8
20....42.0386 .......42.0388 ........Height Adjuster Cross Shaft ............1
21....99.SF0506......99.SF0506 .......5/16-18 x 3/4 Flange Bolt .............3
22....41.0039 .......41.0039 ........9/16 OD x 5/8 Compression Spring ........2
23....64.0678 .......64.0678 ........Height Adjuster Bracket ..............1
24....90.0414 .......90.0414 ........1/4-20 x 1-3/4 Bolt .................1
25....95.04 ........95.04..........1/4SAEWasher ..................2
26....99.A04 ........99.A04 .........1/4-20 Lock Nut ..................1
27....42.0387 .......42.0387 ........Height Adjuster Handle ..............1
28....47.0111 .......47.0111 ........Handle Grip .................... 1
29....64.0668 .......64.0668 ........Height Adjuster Plate ...............1
30....64.0679 .......64.0679 ........Height Adjuster Plate Spacer ...........2
31....99.SF05 .......99.SF05 ........5/16-18 Flange Nut ................3
32....99.A06 ........99.A06 .........3/8-16 Lock Nut ..................6
33....99.SF0608......99.SF0608 .......3/8-16 x 1 Flange Bolt ...............1
34....00.0166 .......00.0166 ........Belt Diagram Decal ................ 1
