Ventrac HM600 - Page 31

FIGURE 6
DECK PARTS
PARTS
E-12
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....60.0662 .......60.0676 ........Deck Shield .................... 1
1.................60.0758 ........Offset Deck Shield, HP720 ............1
2.....00.0192 .......00.0192 ........V-Decal ...................... 1
3.....62.0758 .......62.0764 ........Carrier Frame ................... 1
4.....00.0139 .......00.0139 ........Ventrac Decal ...................1
5.....99.A06........99.A06 .........3/8-16 Lock Nut .................. 3
6.....94.06 ........94.06..........3/8USSFlat Washer ...............6
7.....90.0640 .......90.0640 ........3/8-16 x 5 Bolt ...................2
8.....64.1000 .......64.1000 ........Deck/Carrier Slide Pin ...............2
9.....64.0682 .......64.0682 ........Deck Shield Spring.................1
10....95.05 ........95.05..........5/16 SAE Flat Washer ...............5
11....99.A05........99.A05 .........5/16-18 Lock Nut..................2
12....41.0021 .......41.0021 ........1/2ODx2-3/4 Compression Spring ........1
13....90.0524 .......90.0524 ........5/16-18 x 3 Bolt ..................1
14....90.0612 .......90.0612 ........3/8-16 x 1-1/2 Bolt .................2
15....95.06 ........95.06..........3/8SAEWasher ..................7
16....43.006 ........43.006 .........3/8-24 Spherical Rod End .............4
17....93.06 ........93.06..........3/8-24 Nut ..................... 4
18....99.J0640NFZ ....99.J0640NFZ .....Height Adjuster Rod ................2
19....99.SF06 .......99.SF06 ........3/8-16 Flange Nut .................9
20....42.0431 .......42.0432 ........Height Adjuster Cross Shaft ............1
21....90.0614 .......90.0614 ........3/8-16 x 1-3/4 Bolt .................1
22....90.0508 .......90.0508 ........5/16-18 x 1 Bolt ..................1
23....64.0903 .......64.0903 ........Height Adjuster Bracket ..............1
24....41.0039 .......41.0039 ........9/16 OD x 5/8 Compression Spring ........1
25....40.0289 .......40.0289 ........Height Adjuster Selector Handle..........1
26....47.0086 .......47.0086 ........Handle Grip .................... 1
27....64.0904 .......64.0904 ........Height Adjuster Plate ...............1
28....64.0905 .......64.0905 ........Height Adjuster Plate Spacer ...........2
29....90.0618 .......90.0618 ........3/8-16 x 2-1/4 Bolt .................2
30....99.SF0608......99.SF0608 .......3/8-16 x 1 Flange Bolt ...............1
31....00.0166 .......00.0166 ........Belt Diagram Decal ................ 1
32....90.0610 .......90.0610 ........3/8-16 x 1-1/4 Bolt .................2
33....00.0100 .......00.0100 ........Made in the USA Decal ..............1
