FIGURE 7
CASTER & REAR ROLLER PARTS
PARTS
E-14
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....53.0080 .......53.0080 ........Dust Cap...................... 2
2.....99.A12NF ......99.A12NF .......3/4-16 Locknut ................... 2
3.....55.0023 .......55.0023 .........75x1.78 Ball Bearing...............4
4.....04.0013 .......04.0013 .........068 x 1.75 Internal Snap Ring...........2
5.....99.B0052 ......99.B0052........16ga.x3/4 x 1 Shim ...............2
6.....99.B0057-2 .....99.B0057-2 ......10Ga.x3/4x1-1/4 Machinery Washer ......4
7.....99.A06........99.A06 .........3/8-16 Locknut ................... 2
8.....53.0086 .......53.0086 ........Caster Wheel Assembly ..............2
9.....50.0050 .......50.0050 ........Axle Tube ..................... 2
10....90.0656 .......90.0656 ........3/8-16 x 7 Bolt (Welded 1/4” Caster only) .....
10....90.0660 .......90.0660 ........3/8-16 x 7-1/2 Bolt (Formed 3/8” Caster) .....2
11....50.0049 .......50.0049 ........Caster Spindle ...................2
12....04.0016 .......04.0016 ........1"External Snap Ring ...............2
13....95.16 ........95.16..........1”SAEWasher .................. 4
14....50.0044 .......50.0044 ........EndRoller ..................... 2
15....64.0681 .......64.0681 ........Rear Roller Spacer................. 2
16....99.SF0508......99.SF0508 .......5/16-18 x 1 Flange Bolt ..............4
17....99.SF05 .......99.SF05 ........5/16-18 Flange Nut ................4
18....55.FB16016 .....55.FB16016 ......1"Flange Block Bearing ..............1
19....80.0292 .......80.0293 ........Rear Roller..................... 1
20....95.06 ........95.06..........3/8SAEFlat Washer ...............4
21....55.FB16016-7 ....55.FB16016-7 .....1”Flange Block Bearing ..............1
22....95.12 ........95.12..........3/4SAEFlat Washer (As needed) .........2
23....47.0215 .......47.0215 ........EndCap(QTYper1ofRef8)...........2
24....44.0201 .......44.0201 ........Felt Seal (QTY per 1 of Ref 8) ...........2
25....55.0053 .......55.0053 ........Roller Bearings (QTY per 1 of Ref 8) .......2
26....99.G0013 ......99.G0013 .......Inner Spacer (QTY per 1 of Ref 8) .........4
