Vents VKO - Designation Key; Additional Options

10
DESIGNATION KEY
Vents 100 LD A V K L ____
Power supply parameters other than 220 V 50 Hz
_ – 220-240 V 50 Hz by default
(XV/YHz), where X is the mains voltage, Y is the frequency
Modications
_ – standard
L – motor on ball bearings
Turbo – high-powered motor
Q – with reduced noise level
Q1 – with reduced noise level and high performance
12 – motor with 12 V/50 Hz rated voltage
Press – high pressure impeller
K – non-return valve
Additional options
V – pull cord switch
T – turn-off delay timer
T1 – turn-on and turn-off delay timer
TH – humidity sensor and turn-off delay timer
ТР – motion sensor and turn-off delay timer
K – non-return valve
Decorative front panel
A – brushed aluminium (for the LD series)
N – polished stainless steel (for the LD series)
Fan series
VKO, VKO1, M, MA, M1, M3, MAO1, MAO2, M1OK2, R, R1, K, K1, PF, PF1, F, F1,
D, D1, LD, LD1, S, S1, X, X1, Xstar, Silenta-M, Silenta-S
Outlet spigot diameter [mm]
100, 120, 125, 150
