Venturer STS91 - Connecting the Speakers & Subwoofer; Positioning the Speakers and Subwoofer

E - 13
Setup
(continued to next page)(continued to next page)
(continued to next page)(continued to next page)
(continued to next page)
D. Connecting the speakers & subwoofer
The speaker cords have
been color-coded to
simplify connection.
Just plug the POSITIVE
(+) and NEGATIVE (-)
ends of each speaker
wire into the
corresponding jacks on
the rear of the Unit,
matching the color tube
on the end of the speaker
wire to the color-coded
connector.
E. Positioning the speakers and subwoofer
CENTER
Place on the top of or below the TV.
REAR SPEAKERS
Place right beside or slightly behind
your listening position, and a little
higher than your ears.
SUBWOOFER
Canbeplacedanywhere.
FRONT SPEAKERS
Place on both sides of
the TV, equal distances
apart.
+
FRONT (RIGHT) REAR (RIGHT) REAR (LEFT) FRONT (LEFT)
+
CENTERSUBWOOFER
