12
Replacing the UV-C Bulb
Before replacing the bulb, make sure the vacuum cleaner is switched off and
unplugged from the power outlet.
The life span of the UV-C bulb, under normal use, is 2 to 3 years.
Caution: Use only Verilux
®
bulbs. Use of an incorrect bulb can result in damage.
To order a replacement bulb, use the Component Re-order form included with this
product, or call Verilux Customer Service at 1-800-786-6850 or visit www.Verilux.com.
1. Detach the protective grill on the
bottom of the base unit by pulling
up the two tabs at the back of the
covering. Set the cover aside. (See
Figure 5)
2. Remove the two plastic pieces that
cover the ends of the UV-C bulb.
3. Unscrew the screws surrounding
the protective housing.
4. Using a small pair of pliers at one
end of the bulb, rotate the bulb 90
degrees and remove. (See Figure 6)
Note: UV-C bulb is housed in a glass sleeve
to protect it from accidental damage.
Remove old bulb from this sleeve before
disposal.
5. Insert the new bulb into protective
sleeve and place back into unit. Rotate
bulb by 90 degrees to secure.
6. Relocate the protective housing and
tighten all screws.
7. Relocate the protective grill and snap
back into place.
Figure 6
Figure 5
