USB720 Modem USER GUIDE
9
Using the External Antenna Connector
An optional external antenna and External Antenna Adapter Cable may be purchased (sold separately) for use with
the USB720 Modem. An external antenna is useful when traveling in select fringe coverage areas where the network
signal may be weak.
1. Simply raise the flip-up antenna 90 degrees to locate the External Antenna Connector jack on the USB720
Modem.
2. Remove the rubber protector to expose the External Antenna Connector. (Keep the rubber protector in a
safe place for future use in order to protect the External Antenna Connector from debris when not in use).
3. Connect the External Antenna Adapter Cable to the USB720 Modem’s External Antenna Connector [A].
4. Connect the External Antenna Adapter Cable’s receiving end into the external antenna of your choice [B].
Antenna Cable
B
A
