Luna 2, Luna Basic 2, Luna UL 2
2021-02
Technical specifications
13
EN
NL
5 Technical specifications
The technical details below are only valid for this nursing bed, at standard settings and optimal
ambient conditions. Take these details into account during use.
The values are no longer applicable if your nursing bed has been modified, damaged or suffers
from severe wear.
Luna 2, Luna Basic 2, Luna UL 2
Length
: 2170 mm;
: 2180 mm
Width
: 1020 mm;
: 1015 mm;
: 1025 mm
Height (without lifting pole)
: 840 - 1250 mm ;
: 726 - 1136 mm
Height (with lifting pole)
: 1675 - 2080 mm;
: 1590 - 1995 mm
Height adjustment of the bed
surface (position 1)
Luna 2, Luna Basic 2:
335 mm (without mattress)
Luna UL 2:
205 mm (without mattress)
Luna 2, Luna Basic 2:
745 mm (without mattress)
Luna UL 2:
615 mm (without mattress)
Height adjustment of the bed
surface (position 2)
400 mm (without mattress)
Not for Luna UL 2
810 mm (without mattress)
Not for Luna UL 2
Folded length 445 mm
Folded width 935 mm
Folded height 1045 mm
Total mass
: 98,15 kg;
: 83,7 kg;
: 96,35 kg
Adjustment of the back section 83°
Max. thigh angle 31.7°
Max. angle for lower leg -14,8°
Max. safe load * 200 kg
Lifting pole Nominal load 80 kg
Mattress Min. RG 35, thickness 120 mm, 2000 x 900 mm, max. 20 kg
Under clearance for patient lift 160 mm
Steering casters (4 pieces) Luna 2, Luna Basic 2: Ø 100 mm, can be locked
Luna UL 2: Ø 75 mm, can be locked
Front part of motor LA273100-A01405040, Linak
Back section motor LA270022-00, Linak
Leg section motor LA270022-00, Linak
Handset HBW074-072, Linak
Transformer CB6404+10019, Linak
Nominal voltage, transformer
U input: 230 V, ± 10%, 50 Hz, current: max. 1.5 A, output voltage: 24V ,
max. 70 VA
Period switched on 10%, max. 6 min/hour
Noise level < 65 dB(A)
Class / Kind of protection Protection class II, application part Type B / IP54 (spray protection)
Storage and use temperature + 5 °C + 41 °C
