Versalift VST-8000-I User Manual

3-11
39026-03 02/17VERSALIFT VST-8000/8500/9000/9500-I
SPECIFICATIONS
VST-9500-I DIMENSIONAL SPECIFICATIONS
Note: All dimensions and angles are nominal, based on 40 in. (1.02m) frame height.
General Specifi cations
Horizontal Reach ............................................................................................................... 61 ft 8 in (18.8 m)
Maximum Platform Capacity................................................................................................600 lbs. (272 kg)
Maximum Platform Capacity with Optional Jib Installed ......................................................500 lbs. (227 kg)
Lower Boom Lift Eye Capacity (Optional)..........................................................................1500 lbs. (680 kg)
Maximum Jib Capacity (Optional)......................................................................................1000 lbs. (454 kg)
Standard Pedestal
Height to Bottom of Platform ............................................................................................. 94 ft 9 in (28.9 m)
Working Height ............................................................................................................... 99 ft 10 in. (30.4 m)
Stowed Travel Height .......................................................................................................... 12 ft 5 in (3.8 m)
Weight of Lift without Subframe and Outriggers ............................................................ 9,950 lbs. (4513 kg)
Weight of Lift with standard Subframe and Dual Radial Outriggers ............................ 15,200 lbs. (6895 kg)
Hydraulic System
Operating Pressure ....................................................................................................3000 psi (210 kg/cm2)
Flow Rate ............................................................................................................................ 10 gpm (38 lpm)
Filtration ..............................................................................................................................10 micron Return
100 mesh Suction
System Type ..............................................................................................................................Open Center
Power Source ...............................................................................................................................PTO Pump
Boom Action
Outer/Inner Boom Travel +/- 2° .................................................................................................. -25° to +75°
Lower Boom Travel +/- 2° .............................................................................................................. 0° to +88°
Inner Boom Extension ............................................................................................................. 256 in (6.5 m)
Rotation ............................................................................................................................... 360° continuous
Upper Boom Insulation Gap ................................................................................................. 52 in (1.32 m)
Lower Boom Insulation Gap ................................................................................................. 24 in (0.61 m)
Ambient Temperature Range for Structural Integrity .....................................-40 to 125°F (-40 to 52°C)
