EDGE 500
- Benutzerhandbuch
DE - 13
TECHNISCE DATEN
Number of Drivers 2
Woofer Diameter 8 inch / 209 mm
Voice Coil Diameter 2 inch / 50 mm
Winding Material Copper
Magnet Type Ferrite
Number of Drivers 1
Voice Coil Diameter 1.4 inch / 36 mm
Winding Material Aluminium
Throat Diameter 1 inch / 25 mm
Magnet Tipe Ferrite
Horn Design Elliptical Wave Guide
Horn Coverage 90° Horizontal - 60° Vertical
Maximum SPL Peak
1m 127 dB
Frequency Response 58 Hz ÷ 20 kHz
Crossover frequency 2400Hz
Material Polypropylene – Composite molded high impact enclosure
Handles 2 on the sides – 1 on the top
1 hole on the bottom (for speaker stand fitting).
2 M8 screw mounting holes on the sides
1 hook on the rear (for speaker hanging)
Protections Perforated and painted metal grid
Total Amplifier Power 415W - EIAJ (1kHz, 1% THD)
Max LF output power 350 W
Max HF output power 65 W
Distorsion <0.05% (THD, DIM, SMPTE)
Input sensitivity 0 dBu
Line Input impedance 30 kOhms (balanced) – 15kOhms (unbalanced)
Active protective circuitry Thermal, overload, short circuit, soft clip and voltage limiters
HF protection ptc
Subsonic filter Yes
Gain
Dynamic loudness
High pass filter
ON (Green Led)
Overload / short circuit protection (Red Led)
Thermal protection (Red Led)
Compressor high (Red Led)
Compressor low (Red Led)
Signal (Green Led)
Line Input: Female XLR
Link: Male XLR
AC Connector: 3 pin IEC 250 VAC with fuse
Dimensions (W x H x D) 355 x 635 x 420 mm
Weight 16 Kg
PHYSICAL FEATURES
Coupling
ACOUSTIC RESPONSE
CONSTRUCTION
AMPLIFIER SECTION
CONTROLS
LOW FREQUENCY SECTION
HIGH FREQUENCY SECTION
DISPLAY LEDs
CONNECTORS
