Vertex VT9626+ - Programming Level Parameters

4
■ PROGRAMMING LEVEL PARAMETERS
lst. Prog. Level 2nd. Prog. Level 3rd. Prog. Level 4
th
Prog. Level 5
th
. Prog. Level
SET + < 5sec.
> + <
>
<
<
>
5sec.
1. When 2
nd
Output (Cooling) is not selected, CPb、Cti、Ctd、HYS2 and db parameters
are not available.
2. When Pb≠0.0， HYS1 will be skipped.
3. When CPb≠0.0，HYS2 will be skipped.
4. When Pb＝0.0，ti、td will be skipped.
5. When CPb＝0.0，Cti、Ctd will be skipped.
