8 Push button
Not active (light off): retract
camera gimbal
active (light on): deploy camera
gimbal
9 Gimbal mode selector
A: GRR (hold coordinate on
ground)
B: OBS (keep camera position)
C: STOW (lock in forward view
D: not assigned
E: not assigned
F: not assigned
10 Power button
Press and hold: power on/off
Press: screen on/off
11 Joystick Not assigned
12 Joystick
In hover mode
Stick up: climb
Stick down: descend
Stick left: yaw left
Stick right: yaw right
In fixed-wing mode
Stick up: gimbal up
Stick down: gimbal down
Stick left: gimbal left
Stick right: gimbal right
