LiebertModel
No.
Cabinet Dimensions in. (mm)
A
A* (575V
only)
C D
J Lee-Temp or DSE
Receivers Only
K L M
H
39-5/8
(1006)
57-5/8
(1464)
69-5/8
(1768)
81-5/8 (2073) -- -- --
MCL110
G 35-7/8 (911)
53-7/8
(1368)
65-7/8
(1673)
77-7/8 (1978) -- -- --
H
43-5/8
(1108)
61-5/8
(1565)
73-5/8
(1870)
85-5/8 (2175) -- -- --
Source: DPN003437, Rev. 2
Figure 2.3 Condenser planning dimensional data—MCL165
