Model #
Condenser Connections, OD, In Liebert Lee-Temp Connections
Hot Gas Liquid Hot Gas Tee IDS, In. Liquid Line to Liebert Lee-TempValve, ODS, In.
Receiver Out
Rotalock, IDS, In.
MCS028 7/8 5/8 7/8 5/8 5/8
MCM040 7/8 5/8 7/8 5/8 5/8
MCM080 1-1/8 7/8 1-1/8 7/8 1-1/8
MCL055 1-1/8 7/8 1-1/8 7/8 7/8
MCL110 1-3/8 1-1/8 1-3/8 1-1/8 1-1/8
MCL165 1-3/8 1-1/8 1-3/8 1-1/8 1-1/8
MCL220 1-5/8 1-3/8 1-5/8 1-3/8 1-3/8
Source: DPN002167, Rev. 6
Table 5.2 Condenser piping connection sizes—Single-circuit condensers with Liebert Lee-Temp
Vertiv | Liebert® MC™ Installer/User Guide | 64
