Model
#
Condenser Connections, OD.In Liebert Lee-Temp Connections
Condenser
Circuits
Hot
Gas
Liquid
Hot Gas Tee IDS
In.
Liquid Line to Lee-Temp Valve
ODS, In.
Receiver Out Rotalock
IDS In.
MCS056 2 7/8 5/8 7/8 5/8 5/8
MCM080 2 7/8 5/8 7/8 5/8 5/8
MCL110 2 1-1/8 7/8 1-1/8 7/8 78
MCL160 2 1-1/8 7/8 1-1/8 7/8 1-1/8
MCL220 2 1-3/8 1-1/8 1-3/8 1-1/8 1-1/8
Source: DPN002426, Rev. 6
Table 5.4 Condenser piping connection sizes—Dual-circuit condensers with Liebert Lee-Temp
