Item No. Description Qty
1 Receiver and Bracket Assembly 2
2 Cap Screw HXDIN933M8-1.25X25A2 12
3 Fender Washer DIN9021 M8X24 A2 20
4 Lock Nut Hex NYL INSR M8 12
5 Clamp Omega 7/8” 1
6 Screw SD HWH YZ 10-16 x 5/8 2
7 90° Elbow FTGXFTG 7/8” Copper 2
8 Copper Formed Tube 1-1/8” 2
9 Copper Formed Tube 1-1/8” 1
12 Coupling Copper 1-1/8” 1
14 Reducer Copper CXC 1-1/8”x7/8” 3
15 Support Leg 2
16 Fastener Assembly: Cap Screw, Lock Washer, Fender Washer 8
18 Copper Tube 1-1/8” Swaged 1
19 90° Elbow CXC 1-1/8” Copper 1
20 90° Elbow CXC 1-1/8”X7/8” Copper 1
Vertiv | Liebert® MC™ Installer/User Guide | 73
