Vestas V117-4.0 MW User Manual

6 General information 0011461397
See ‘Safety regulations for operators and technicians’ for general instructions for how to do a
safe stop of the wind turbine and how to prepare the wind turbine before evacuation and rescue.
0057-0583 ‘Evacuation, escape, and rescue plan’ has all the relevant information and will be
made available on site. All personnel will be trained according to the evacuation instruction and in
the proper techniques for evacuation, rescue, and escape during an emergency.
Evacuation, escape and rescue instruction for onshore wind turbine
Document no.: 0067–2397 V00 · Class: RESTRICTED · Type: T09
Page 8 of 33

Vestas V117-4.0 MW Specifications

General

Rated Power	4.0 MW
Rotor Diameter	117 m
Cut-in Wind Speed	3 m/s
Rated Wind Speed	12 m/s
Cut-out Wind Speed	25 m/s
Swept Area	10, 751 m²
Turbine concept	Upwind
Operational Wind Speed	3-25 m/s
Operating Temperature Range	-20°C to +40°C
Tower Type	Steel tubular
Power Regulation	Pitch
