HANDY TRAX USB (BOM)
Lvl Materials SPECS Qt
y
Part Location
.1 BASP10177 SPEAKER 3 8 OHM 2W 1
36
.1 BE1704506B BELT 1
40
.1 BK18 LUG 1
37
.1 ERE76SUS 6MM E RING 1
26
.1 LAC67MON95 LABEL ( ROHS) 2
52
.1 LAP14TMV17 VOLTAGE LABEL 1
49
.1 LAP22TMV03 LABEL (SERIAL NO ) 1
50
.1 LAP63TMV08 LABEL DATE (20 X 6MM) 1
51
.1 MT390180101 SIGNAL EARTH PLATE 1
16
.1 MT390300201 STUD HEAD SHELL 1
13
.1 MT390440101 METAL PLATE (SIGNAL) 1
17
.1 MT3904402 METAL PLATE (USB) 1
46
.1 MT390460101 FIXED METAL (BATTERY) 2
14
.1 MT6705501P CENTER SHAFT 1
31
.1 NM3910601 VELVET CARPET (KNOB) 1
22
.1 NM3930301 VELVET CARPET 1
53
.1 NUT0104INI SCREW NUT 1
N
11
.1 PA1002010B TONE ARM ASS'Y ( PT1) 1
..2 CR800-9 CERAMIC CARTRIDGE 1
30
..2 ERE75 5MM E RING 1
8
..2 MT390100301 LUG 1
9
..2 MT390100501 CENTER SHAFT ASS'Y 1
...3 MT390100401 METAL PLATE (ARM) 1
4
...3 MT390300101 CENTER SHAFT (ARM) 1
7
..2 MT390160202 COUNTER WEIGHT 1
3
..2 MT5301301 STUD 1
5
..2 PST020010TYH TUBE (2.0 X 10MM) 2
28
..2 PT390120101 PLASTIC ARM BASE 1
1
..2 SC0310FABI SCREW 1
N
1
..2 SP3901602 SPRING 1
27
..2 TE10100 CONNECTOR (BIG PIN) 2
..2 WR0036130B1 ARM WIRE 130MM (BLACK) 1
54
..2 WR023246021G CONNECTOR WIRE 1
2
.1 PT1110627 KNOB 1
20
.1 PT2002202 45RPM ADAPTOR 1
33
.1 PT390300101 STUD HEAD SHELL 1
11
.1 PT390300201 FIXED BASE (ARM) 1
12
.1 PT390440101 PLASTIC FIX PLATE (HINGE) RIGHT 1
39
.1 PT390440201 PLASTIC FIX PLATE (HINGE) LEFT 1
38
.1 PT390440301 FIXED LUG 1
42
.1 PT390460102
BATTERY COVER (PT1U) SPRAYING PEARL WHITE
123
..2 PT390460101 BATTERY COVER (PT1U) RM 1
.1 PT390470102
MOTOR COVER (PT1U) SPRAYING PEARL WHTIE
132
..2 PT390470101 MOTOR COVER (PT1U) RM 1
.1 PT391060101 KNOB 2
19
.1 PT391060201 BUTTON (OPEN /CLOSE) 1
18
.1 PT393010103
TOP COVER (PT1U) S/P (PEARL WHITE/HANDY TRAX USB)
125
..2 PT393010101 TOP COVER (PT1U) RM 1
.1 PT393020302
CABINET (PT1U) S/P PEARL WHITE/VESTAX
134
..2 PT3930203 CABINET (PT1U) RM 1
.1 PT393030401
BOTTOM BOARD (PT1U) SPRAYING METALIC BROWN
124
..2 PT3930304 BOTTOM BOARD (PT1U) RM 1
.1 PT5305207AEL
PLATTER (DL280N W/STAMPING) (EHS COMPLIANCE)
129
..2 MT2005601
COPPER INSERT (CHANGE FROM SB56)
1
..2 PT5305207
PLATTER (DL-280N) (EHS COMPLIANCE)
1
.1 RU390300101 RUBBER (ARM) 1
10
.1 RU4109301 CUSHION MOTOR 3
41
.1 SC0308WBNI SCREW 4
N
8
.1 SC0310RBNI SCREW-RoHS 12
N
2
.1 SC0312RIZI SCREW 1
N
3
.1 SC0316RBNI SCREW 8
N
4
.1 SC2608W8INI SCREW 3
N
11
