Vestax HANDY TRAX USB User Manual

Lvl Materials SPECS Qt
y
Part Location
.1 SD35055000RJP LAMIN BAG 1
.1 SD400290 LAMIN BAG 1
.1 SP3903001 SPRING 1
6
.1 SP3904601 SPRING (BATTERY) 2
43
.1 TF35021401EU ADAPTOR(EU) 12VAC,300MA 1
.1 TWME7I60T22 MOTOR ASS'Y 1
..2 ME7I60T22 MOTOR 1
45
..2 P6809501 PULLEY MOTOR 1
44
.1 TWPC02P00102 PCB ASS'Y (PT1) 1
..2 PC02P001 P.C. BOARD (PT1) 1
..2 TWPC02P001A02 PCB ASS'Y (CONTROL) 1 21
...3 CC10450T C. CAP 0.1UF/50V 1
C5
...3 CC33150T C. CAP 330PF/50V 6
C101, 105, 107, 201, 205, 207
...3 JW5206T JUMPER WIRE (A.I.) 52MM 7
J01, 02, 03, 06, 07, 08, 11
...3 R03316T5 RESISTOR 3.3 OHM 1/16W 2
R109, 209
...3 R10216T5 RESISTOR 1K 1/16W 2
R19, 20
...3 R10316T5 RESISTOR 10K 1/16W 2
R106, 207
...3 R10416T5 RESISTOR 100K 1/16W 2
R108, 208
...3 R10516T5 RESISTOR 1M 1/6W 2
R101, 201
...3 R12216T5 RESISTOR 1.2K 1/16W 1
R10
...3 R15116T5 RESISTOR 150 OHM 1/6W 1
R17
...3 R18216T5 RESISTOR 1.8K 1/6W 1
R8
...3 R22016T5 RESISTOR 22 OHM 1/6W 1
R7
...3 R22216T5 RESISTOR 2.2K 1/16W 1
R6
...3 R24316T5 RESISTOR 24K 1/6W 1
R13
...3 R27116T5 RESISTOR 270 OHM 1/6W 2
R103, 203
...3 R27216T5 RESISTOR 2.7K 1/16W 1
R113
...3 R30116T5 RESISTOR 300 OHM 1/6W 2
R12, 16
...3 R47216T5 RESISTOR 4.7K 1/16W 1
R15
...3 R51216T5 RESISTOR 5.1K 1/6W 1
R4
...3 R56316T5 RESISTOR 56K 1/6W 2
R102, 202
...3 R68016T5 RESISTOR 68 OHM 1/6W 1
R9
...3 R68116T5 RESISTOR 680 OHM 1/6W 1
R1
...3 R75216T5 RESISTOR 7.5K 1/6W 2
R2, 5
...3 R82416T5 RESISTOR 820K 1/6W 2
R213, 223
...3 R91116T5 RESISTOR 910 OHM 1/16W 1
R18
...3 R91216T5 RESISTOR 9.1K 1/6W 1
R3
...3 EC10650TM E. CAPACITOR 10UF/50V 1
C6
...3 EC10716TM E. CAPACITOR 100UF/16V 3
C108, 112, 208
...3 EC47550TM E. CAP 4.7UF/50V 4
C102, 103, 202, 203
...3 EC47716TM E. CAP 470UF 16V 4
C110, 111, 114, 210
...3 MC10450TTF M.CAP 0.1UF/50V (JL3) 2
C109, 209
...3 MC68350TTF M.CAP 0.068UF/50V(J) TF (B) 2
C104, 204
...3 TR2SC2120Y TRANSISTOR 2SC2120Y 2
TR01, 02
...3 IC4261 IC 4261 1
IC3
...3 IC5527 IC (5527) 1
IC2
...3 NM1106112 VELVET CARPET 1
VR3
...3 SV20205 2K SEMIFIXED RESISTOR 1
SV01
...3 SV22305 SEMIFIXED RESISTOR B22K 1
SV03
...3 SV50205 SEMIFIXED RESISTOR 5K 1
SV02
...3 SWSL10030-0403 SWITCH (OPEN/CLOSE) 1
SW03
...3 SWVS6P001 SWITCH 1
SW1
...3 TE612000301 3P CONNETOR SOCKET 1
TE17
...3 TE812000211 2P CONNECTOR SOCKET 4
TE05, 06, 07, 11
...3 TE812000311 3P CONNECTOR 1
TE10
...3 VRR1032001 VARIABLE RESISTOR B10K 1
VR1
...3 VRR1032002 VARIABLE RESISTOR B10K 1
VR2
...3 VRS50204505 VARIABLE RESISTOR B5K-DR141 1
VR3
...3 WR1134022G1 3P CONNECTOR WIRE 340MM 1
TE08 (to) TE15
...3 WR1137022G1 3P CONNECTOR WIRE 370MM 1
TE09 (to) TE14
..2 TWPC02P001B02 PCB ASS'Y (POWER) 1 15
...3 CC10450T C. CAP 0.1UF/50V 2
C1, 3
...3 DI1N4002T5 DIODE IN4002 5
D1, 2, 3, 4, 5
...3 DIZDMTZJ91BT ZENER DIODE 9.1B 1
ZD01
