Vestax HANDY TRAX USB User Manual

Lvl Materials SPECS Qt
y
Part Location
...3 JW5206T JUMPER WIRE (A.I.) 52MM 3
J04, 05, 06
...3 R06201T5 RESISTOR 6.2 OHM 1W 2
R21, 22
...3 R10116T5 RESISTOR 100 OHM 1/16W 2
R110, 210
...3 R22016T5 RESISTOR 22 OHM 1/6W 2
R114, 214
...3 R47216T5 RESISTOR 4.7K 1/16W 1
R14
...3 R47316T5 RESISTOR 47K 1/16W 2
R112, 212
...3 R47416T5 RESISTOR 470K 1/6W 2
R111, 211
...3 EC22716TM E. CAP 220UF/16V 1
C7
...3 EC47616TM E. CAP 47UF/16V 1
C8
...3 TR2SD1768S TRANSISTOR 2SD1768S 1
TR03
...3 CN0220001002 2P EARTH WIRE 1
TE13
...3 CN0220002001 2P CONNECTOR WIRE 3
(TE07, 01), MOTOR(TE08, 03),
AMP
(
TE11,03
)
...3 CN0320002101 3P CONNECTOR WIRE 210MM 1
(TE10,12)
...3 EC10825EM E. CAPACITOR 1000UF/25V 1
C2
...3 JK-3537 STEREO f3.5MM PHONE JACK 2
JK01, 02
...3 JKDJ-0702B-020 DC SOCKET 2.0MM 1
JA03
...3 MC473100K M. CAP 0.047UF/100V 1
MC01
...3 RJ-1039-0380B RCA JACK 1
RJ01
...3 TE812000211 2P CONNECTOR SOCKET 3
TE01, 02, 13
...3 TE812000311 3P CONNECTOR 1
TE12
...3 TE812000411 4P HEADER SIL 2MM MALE SHRD 1
TE03
...3 WCB35 WIRE BLACK 350MM 2
TE02(-), W1
...3 WCR14 WIRE RED 140MM 1
TE02(+)
..2 TWPC02P001C01 PCB ASS'Y (P/S) 1 35
...3 CN0220001701 2P CONNECTOR WIRE 170MM 1
TE16(M+-)SWITCH2
...3 CN0220003501 2P CONNECTOR WIRE 350MM 1
TE16(M+-)MOTOR
...3 SWDM03L-2P SWITCH (XL-500II) 1
SW2
...3 TE812000411 4P HEADER SIL 2MM MALE SHRD 1
TE16
.1 TWPC08P02401 PCB ASS'Y (USB) 1 47
..2 CS104K5005X7R CHIP CAP 0.1UF ±10% 50V 0805 3
C2,12, 14
..2 CS105K1005X7R CAPACITOR SMD 1UF/10V 10% X7R 7
C3, 4, 6, 8, 9, 11, 13
..2 CS180J5005NPO C. CAP. SMD 18 pF 50V 5% 0805 NPO 2
C7, 10
..2 CS331J5005NPO C. CAP. SMD 330 pF 50V 5% 0805 NPO 4
C15, 21, 26, 30
..2 ICNJM2387 IC NJM2387 1
IC1
..2 ICOPA2353UA IC OPA2353UA 1
IC2
..2 ICPCM2902E-1 IC PCM2902E-1 1
IC4
..2 PC08P024 P.C. BOARD 1
..2 RS000008J05 CHIP RES. 0 Ω 5% SMD 0805 7
R5, 6, 7, 10, 17, 21, 32
..2 RS001M08F05 CHIP RES. 1M Ω 1% SMD 0805 1
R14
..2 RS002208F05 CHIP RES. 22 Ω 1% SMD 0805 2
R8, 9
..2 RS010008F05 CHIP RES. 100 Ω 1% SMD 0805 2
R24, 31
..2 RS012K08F05 CHIP RES. 12K Ω 1% SMD 0805 2
R22, 33
..2 RS01K508F05 CHIP RES. 1.5K Ω 1% SMD 0805 4
R4, 11, 12, 13
..2 RS03K308F05 CHIP RES. 3.3K Ω 1% SMD 0805 1
R2
..2 RS03K908F05 CHIP RES. 3.9K Ω 1% SMD 0805 2
R23, 34
..2 RS047K08F05 CHIP RES. 47K Ω 1% SMD 0805 2
R25, 30
..2 RS04K708F05 CHIP RES. 4.7K Ω 1% SMD 0805 1
R1
..2 RS06K808F05 CHIP RES. 6.8K Ω 1% SMD 0805 1
R3
..2 RS220K08F05 CHIP RES. 220K Ω 1% SMD 0805 2
R16, 36
..2 AL4-08-0402
CON USB SOCKET 4 PIN FEMALE PC-MNT HORIZONTAL
1
USB1
..2 BALO-01 LED HOLDER LO-01 1
LED1
..2 EC10650TM E. CAPACITOR 10UF/50V 8
C1, 5, 17, 19, 25, 27, 28, 31
..2 LD-005HLV LED RED 1
LED1
..2 TE612000301 3P CONNETOR SOCKET 1
CN1
..2 VRR50302005
VARIABLE RESISTOR TOTARY 50KA*2
1
VR1
..2 XTM12000X3 CRYSTAL 12MHz 1
X1
.1 WR1130032G1 3P CONNECTOR WIRE 300MM 1
.1 WS070409IN WASHER 7X0.4X0.9MM 1
N
9
.1 WS109506205M WASHER 2
N
7
.1 WS127705P WASHER 1.2X7.7X0.5MM 1
N
5
.1 WS184315IZ WASHER 18X4.3X1.5 2
N
6
.1 BAUSBCD26 USB CD (PT1U) 1

Vestax HANDY TRAX USB Specifications

General

Brand	Vestax
Model	HANDY TRAX USB
Category	Turntable
Language	English
