14
INSTALLATION OF THE APPLIANCE
WARNING:
The electrical connection of this hob should be carried out by a qualified electrician,
according to the instructions in this guide and in compliance with the current regulations.
In the event of any damage that occurs as a result of improper connection or
installation, the warranty will not be valid. This appliance must be earthed.
Installation safety
· Any overhanging surface should be at least 65cm above the hob.
· Extractor fans must be fitted in accordance with the manufacturers instructions.
· The wall in contact with the rear of the hob must be made of flameproof material.
· The power cable length should not exceed 2 metres.
Fitting the hob into a work surface
· The hob can be inserted into any worktop provided it is heat resistant up to at least
90ºC.
· Create an opening with the dimensions shown in the picture below and on next
page.
· Induction hob may be built in the 25 to 40 mm thick worktops.
