- 2 -
MAIN CONSTRUCTION
1. Motor casing
2. Carbon brush cover
3. Back cover
4. Handle
5. Switch
6. auxiliary handle
7. cover
8. flange
9. wheel
10. saw blade
MAIN SPECIFICATIONS
Model
Power
Supply(V/Hz)
Input(W)
Maximum
Cutting
Depth（inch）
Saw
Blade
Size(mm)
No-load
speed
（RPM）
G.W.
(kg)
DC425
120/60
3200
6
φ410
3200
19.5
MARKINGS
The manufacturer is required to apply the following markings:
• Products shall be marked with the markings specified by the particular product standard.
• Products certified for Canada shall have all Caution and Warning markings in both English
and French.
Additional bilingual markings not covered by the product standard(s) may be required by the
Authorities Having Jurisdiction. It is the responsibility of the manufacturer to provide and
