- 9 -
9. " " Button
In dc current measurement function, press this "
" button to zero the
display before measurement. Press again to undo the zeroing.
In other measurement functions, this button is used to enter/exit Relative
mode.
10. Rotary Switch
Used to select a desired function or range as well as to turn on or off the
meter.
To save battery charge, set this rotary switch to " OFF " position to turn off
the meter when the meter is not in use.
11. " " Button
Briefly press this " " button to enter or exit Data Holdmode.
Press and hold down this button for about 2 secs toturn on or off the
illumination LED
12. Tactile Barrier
Used to prevent finger from touching the conductor under test.
Do not
hold the meter anywhere beyond the tactile barrier.
13. RED LED
An indicator used in non-contact ac voltage detection and continuity test.
14. Illumination LED
15. NCV Sensor
