Vex Protobot - Page 2

2
[5/64”]x1 [3/32”]x1 [WRENCH]X1
[SS2] 1/4” MOTOR SCREW
[SS4] 1/2” MOTOR SCREW
[OPTIONAL ACCESSORY]
[S4] 1/2” SCREW
[5/64”]
[COL] COLLAR
[5/64”]
[BR] POP RIVETS
[BF] BEARING FLAT
[BF] BEARING FLAT
[3/32”]
[S3] 3/8” SCREW
[S2] 1/4” SCREW
[1/4”]
[BO.5, 1, 2, 3]
[NK] 8-32 KEPS NUT
[11/32”]
1
3
5
2
4
6
