Make sure to line up the
holes of 228-2500-141 and
228-2500-215 as shown
Assurez-vous d’aligner les
trous de 228-2500-141
et 228-2500-215 comme
montré
1
2x
2x
228-2500-112
228-2500-215
2x
2x
228-2500-112
228-2500-011
3x
228-2500-060
2x
228-2500-170
1x
1x
228-2500-061
228-2500-026
2x
228-2500-065
