31
FLX-20
™
OPERATION
Setting the Range
The FLX-20 has a total of eleven depth ranges to allow you
to get maximum display resolution for the shing conditions
you are in. The primary ranges for the FLX-20 will be in the
normal settings starting with 0–10 feet.
Mode Control
Control advanced features,
such as zoom, power and
color. See next page.
Interference Rejection
Press the Gain Control repeatedly until the interference
goes away or is reduced as much as possible. There are
20 settings to cycle through.
Color Select
While the Mode Control is set
to CS, push on the Gain Control
to cycle through the three color
palettes. See page 34.
Gain Control
Keep the gain low. Increase it only enough to see clear
bottom or your bait. The Gain Control also acts as a feature
select switch when you push in. See next page.
The x2 setting will mean you will need to double the depth on the display so you now have a 0–20 foot display, the x3 is 0–30, the x4
is 0–40, x8 is 0–80 foot and x10 will mean a 0–100 foot scale. You can also activate the other set of depth settings for super deep water
shing to 300 feet. See the next page for instructions.
