40
FLX-28
™
OPERATION
Green Foot Markers Range Setting
1ft 10 – 30ft
5ft 40 – 60ft
10ft 80 – 300ft
Multi-Layer Display
The FLX-28 incorporates a three-layer LED, spinning wheel display. The
outer color display layer is like our standard three-color Vexilar asher display.
However, with data transfer technology, we can oer more color palettes.
The inner layer on the display shows green marker for every foot of depth.
This makes it easy to position your bait one or two feet o the bottom without
guessing. As you change depth ranges, the green markers will correspond to the
depth changes as shown in the table below.
The third inner layer of the display will be in red and indicates the current
Digital Depth and Range settings. This area is also used to display battery levels,
IR setting levels and Mode settings.
Color Select
The FLX-28 includes ve optional color palettes from which to choose. Set the
Mode Control to the CS position, then press in on the Gain Control to cycle
through the available palettes. See page 56 for an explanation of each.
