59
Battery Compartment
To remove the battery, remove
the four rear section screws.
Transducer Holder
Store the transducer in the
special holder above the battery.
The holder is designed to accept
most styles of Ice-Ducers.
Cable Storage
Place extra cable
into the storage
compartment under
the flasher unit.
Eye-Bolt
Insert the transducer support eye-bolt at the front of the
unit. Be sure to remove the float from the transducer
cable when using the eye-bolt. The eye-bolt is
commonly used on lakes with thin ice conditions.
Easy Charge Jack
Charge the battery
here. You do not
need to disconnect
the battery
connections while
charging.
To Next Page
