2．2 CombinationsandTypesofMotorsandDrivers
FBLⅡ series motors and drivers are provided in sets. When you receive a set, check that you have the proper motor and driver
combination.
※ UnitModelnameisnottherecognizednameandcertifiednameunderthevarioussafetystandards.
Recognizednameandcertifiednamearemotormodelnameanddrivermodelname.
■Combination types
Withcombinationtypeunits,themotorandgearheadarepre-assembled.Mountingscrews,nuts,washers,springwashersand
keysareincludedwiththesemodels.
Thegearratioappearsatthepositionintheunitmodelnumberindicatedbythesquare.
Forexample,FBL575AW-50 meansthatthemodelisequippedwithagearwitha1:50gearratio.
■Separate types(gearheads are sold separately for pinion shaft type motors.)
Thegearratioappearsatthepositioninthemodelnumberindicatedbythebox(□).
Note The unit combinations are as above the mentioned. Note that it cannot be used in any other combinations.
Unit Model ※
FBL575AW-□
FBL575CW-□
FBL575SW-□
FBL5120AW-□
FBL5120CW-□
FBL5120SW-□
Motor Model
FBLM575W-GFB
FBLM575W-GFB
FBLM575W-GFB
FBLM5120W-GFB
FBLM5120W-GFB
FBLM5120W-GFB
Driver Model
FBLD75AW
FBLD75CW
FBLD75SW
FBLD120AW
FBLD120CW
FBLD120SW
Unit Model ※
FBL575AW-A
FBL575AW-GFB
FBL5120AW-A
FBL5120AW-GFB
FBL575CW-A
FBL575CW-GFB
FBL5120CW-A
FBL5120CW-GFB
FBL575SW-A
FBL575SW-GFB
FBL5120SW-A
FBL5120SW-GFB
Motor Model
FBLM575W-A
FBLM575W-GFB
FBLM5120W-A
FBLM5120W-GFB
FBLM575W-A
FBLM575W-GFB
FBLM5120W-A
FBLM5120W-GFB
FBLM575W-A
FBLM575W-GFB
FBLM5120W-A
FBLM5120W-GFB
Shaft Type
Round Shaft
Pinion Shaft
Round Shaft
Pinion Shaft
Round Shaft
Pinion Shaft
Round Shaft
Pinion Shaft
Round Shaft
Pinion Shaft
Round Shaft
Pinion Shaft
Gearhead Model
GFB5G□
GFB5G□
GFB5G□
GFB5G□
GFB5G□
GFB5G□
4
Driver Model
FBLD75AW
FBLD120AW
FBLD75CW
FBLD120CW
FBLD75CW
FBLD120CW
