Vexta FBL II Series User Manual

2. Verifying the Product Name and Accessories
2．1 Motors,DriversandAccessories
Checkthatthemotor,driverandanyaccessoriesareallpresent.Ifanaccessoryismissingordamaged,contactthenearest
ORIENTALMOTORoffice.
・Motor .......................................................1piece ・SignalCableforexternalspeedpotentiometer
TheO-ringsarefittedinthepilotsectionof (1mlong)..................................................1piece
pinionshafttypemotors. ・Setofmountingbolts
・Driver.......................................................1piece (providedonlywithcombinationtypes)
・Driverbasemountingbracket .............2pieces M8bolts....................................................4pieces
Driverbackmountingbracket..............1piece Nuts...........................................................4pieces
Mountingscrews ....................................4pieces Spriingwashers .......................................4pieces
・Externalspeedpotentiometer...............1piece Washers....................................................4pieces
Variableresistor(20kΩ,1/4W) Key ............................................................1piece
・Manual(Thisdocument)..........................1piece
3
Motors and Drivers have been designed and inspected according to the following standards.
Unit Model name is not the recognized name and the certified name under the various safety standards.
Recognized name and certified name are motor model name and driver name.
※ Application of EN standard for FBL575SW-□ type and FBL5120SW-□ type is pending.
Note The EMC measurements required under standard EN50178 are not performed separately for motors and
drivers. Perform the EMC test when they are incorporated into the final product.
The over-voltage protection test required under standard EN50178 is not performed. Perform the test when
incorporated into the final product.
Standards
UL1004
CAN/CSA C22.2 No.100
EN60950
EN60034-1
EN60034-5
UL508C
CAN/CSA C22.2 No.14
EN60950
Motor
Driver※
Certification Body Standards File No.
UL File No. E62327
DEMKO Certificate No.124888/DK 98-03353
UL File No. E171462
DEMKO Certificate No.124886/DK 98-03350
CE Marking
Low Voltage
Directive
Installation Conditions Overvoltage category Ⅱ, Pollution degree 2, Class Ⅰ（For EN Standard）
When the machinery to which the motor and driver are mounted requires
overvoltage category Ⅲ and pollution degree 3 specifications,
install the motor and driver in a cabinet that complies with IP54 and
connect to power supply via an isolation transformer.
