(3) Assembling the Motor and Gearhead (Pinion shaft motor)
Continuetothenextpageifyouhavearoundshafttypeorcombinationtypemotor.
Whenattachingapinionshafttypemotortoagearhead,usethe
pilotofthemotorandgearheadasguides,andgentlyrotatethe
gearheadbackandforthuntilitfitsinplace,asshowninthe
figureattheleft.Whenthegearheadisinplace,fastenittothe
motorusingthescrewsprovided.
Note Clean any dirt off the pilot section of the motor and gearhead.
Insufficient cleaning may cause incomplete attachment and leaking of grease within the gearhead.
Don't pinch the O-ring when assembling the motor and gearhead.
(4) Installing on Other Devices
■Combination Type And Pinion Shaft Motor
Toinstallmotorandgearheadtomachinery,makeinstallation
holesinthemountingplace.
Usescrewsprovidedwithgearheadandsecurethemotorso
thattherearenogapsbetweenthemotorflangesurface,
gearheadsurfaceandthemountingsurface.
Fordimensionsofinstallationholesandthedetailof
mounting,seetheoperatingmanualofgearhead.
■Round shaft Motor
Toinstallmotortomachinery,makeinstallationholesinthe
mountingplace.
Use4screwsandsecurethemotorsothattherearenogaps
betweenthemotorflangesurfaceandthemountingsurface.
Fourscrewsarenecessaryformounting(notprovided).
6
Motor
Gearhead
Mounting
plate
Screws provided
with gearhead
Plain washer
Spring washer
Nuts
Motor
Mounting
plate
Screws
Plain washer
Spring washer
Nuts
Motor
Motor and gearhead assembly screws
(Use 2screws)
Gearhead
Pilot Section
(with O-ring attached)
Pilot Section
Clamping Torque
10N･m (100㎏f㎝)
Motor and Gearhead assembly screws Size : M3
Screw size
M8
