Speaker
Simulator
Effects
Speaker
Outputs
Speaker
Output
Pad*
Effects devices,
Switcher, etc.
Left output Right output
Speaker Speaker
Head
2150 or Classic
Power amp
A
Input
B
Input
A
Input
B
Input
Speaker Speaker
Speaker Speaker
A/Mono
Input
Speaker
Output
Speaker
Output
2150 or Classic
Power amp
Speaker
Note: In this configuration, the input level switch
on the power amplifier is a sufficient pad when con-
necting directly to a speaker output. The input sensi
-
tivity switch must be set to “Lo.” Do not insert sig-
nal-processing devices between the head and power
amp in this setup.
Head
Speaker
Outputs
Speaker
Output
Head
2150 or Classic
Power amp
Speaker
Output
Speaker
Output
* See Connecting To A
Guitar Amplifier, page 11.
