VHT SPECIAL 6 - Rear Panel Connections

B. THE REAR PANEL
Fig. 2: The Rear Panel
9. Footswitch Jack: Plug the preamp gain Boost footswitch into this jack.
10. Speak Jacks: Plug a 4-ohm, 8-ohm,16-ohm cabinet into the appropriate jack. The special 6 Combo’s internal speaker is disconnected when an
external jack is used.
11. Power IEC Socket: Use the included power cord with this unit in accordance with the voltage and frequency ratings listed on this manual and
rear panel of this amplifier.
9
10
11
7
