VIA SEATING USER GUIDES . VIASEATING.COM . 1-800-433-6614
Chair Adjustment Guide: Adjustable Arms
Adjustable Arms #51A/#51AG/#52A/#53A
Arm Height (Up/Down)
Type: Button
Press the button found
beneath the armrest
while grasping the
armrest with both hands.
Raise or lower each
arm to desired height.
Release the button.
Optional Arm Width (In/Out)
Type: Switch
Rotate the switch located
beneath the arm forward.
Use your hand to grasp the
arm and adjust it out to your
desired width away from seat.
Each arm adjusts separately.
When nished making
adjustments, rotate the switch
back to its original position.
Optional Armrest Back/Forth
Type: Armrest
Grasp armrest & slide it forward
or back to desire position.
Armrest slides forward a max of
1.5".
< Watch our 51A/51AG/52A/53A
Online User Guide
Left
Right
Optional Armrest Rotation
Type: Armrest
Grasp armrest and turn left
or right to rotate a max of
15° each way.
