5. Order, delivery and assembly
5.1 Order
In the order the following is needed to be specified:
1) Furnace design - VIADRUS U 22 C furnace
- VIADRUS U 22 D furnace
2) Furnace size.
3) Demands on optional accessories.
5.2 Delivery and accessories
The VIADRUS U 22 furnace is delivered according to the order in a manner that a complete boiler drum
is located on the palette and a covered boiler jacket is fixed on the side. The accessories are stored inside
the boiler drum and is available after opening the stoker hole. The furnace is covered in the transfer packing
and must not be turned over during the transit, only a declination into sides for taking down of the boiler drum
packing is allowed.
Standard accessories for the VIADRUS U 22 furnace:
• cleaning tools (hook, brush with shaft, point, hanger)
• control box 1 piece
• thermomanometer 1 piece
• impregnating and clearing plug Js 1/2“ 1 piece
• draught regulator complete 1 piece
• closure Js 6/4“ 2 pieces
• rod with a control handle of the
smoky flap 1 piece
• control label of the smoky flap 1 piece
• stifling screw 1 piece
• connecting pin of the jacket 4 pieces
• fan-shaped washer 5 4 pieces
• nut M5 4 pieces
• washer 10,5 8 pieces
• nut M10 8 pieces
• flexible pins 3 x 26 1 piece
• split pin 2,5 x 32 1 piece
• washer 10,5 3 pieces
• bushings HEYCO 2 pieces
• blind flanges 6 pieces
• screws into metal C 4,8 x 13 4 pieces
• flange of heat water DN 70 1 piece
• flange of returnable water DN 70 with a socket Js 1/2“ for impregnating and clearing plug 1 piece
• sealing φ 90 x 60 x 3 2 pieces
• operating key 1 piece
• hook 2 pieces
• socket 8 mm 2 pieces
• boiler operation and installation manual
