Allen Key
Cup1/2-131/2-13
*
100L
Φ 13x Φ20x2t
Φ 8x Φ 16xlt
M6xP1. 25x16L
*
1
*
1
*
2
*
2
1
2
3
10
www.viavito.com
Step Three.
01 Remove the bolt (26), the washers (28)
and the nut (27) from the aluminium
rail (71).
02 Release the bungee cord and unhook
the carabiner, putting the cord to one
side.
03
To do this, remove the two screws,
screws loosely on the rail (71), as per the
inset diagram.
04 Insert the aluminium rail (71) on to the main
position with the bolt, the washers and the
nut you removed in part 1 of this step.
05 Unscrew the screws (90) and the
washers (92) at the rear of the
aluminium rail (71).
06 Attach the rear foot (72) to the aluminium
rail (71) using the screws (90) and the
washers (92) you removed. It may be
easier to perform points 5 and 6 with the
rail lifted into the vertical position.
To Next Page
