Vicks VNT275CA User Manual

4
Section 1: Overview
Description of Non Contact Infrared Body Thermometer
• Device principle and introduction:
The Non Contact Infrared Body Thermometer is a hand-held, reusable, battery operated
device, which can measure human body temperature using the forehead as the
measurement site (the skin temperature on one’s forehead). The operating principle is based
on Infrared (IR) Sensor technology. When measuring, the IR Sensor acquires infrared energy
from the target forehead. Taking into account the ambient temperature, the thermometer
turns the signal from the IR Sensor to a digital value and displays it on the LCD.
• Description on Controls, Indicators, and Symbols
Figure 1: VNT275CA Non Contact Infrared Body Thermometer
1. LCD Display
2. Battery Cover
3. On (Trigger)
Button
1. Surface Mode
2. Body Mode
3. Digital Display
4. Smile or Cry Indicator
5. Battery Indicator
Surface M
Body
°
C
°
F
1
2
3
4 5 6
7
8
9
10
4. SET Button
5. MEMO Button
6. MODE Button
7. IR Sensor
6. Voice On/Off indicator
7. Memory Number
8.°F
9. °C
10. Memory

Vicks VNT275CA Specifications

General

Response Time	1 second
Auto Power Off	Yes, after 30 seconds of inactivity
Display	LCD
Measurement Range	32.0°C to 42.9°C (89.6°F to 109.2°F)
Accuracy	±0.2°C (±0.4°F) between 35.5°C to 42°C (95.9°F to 107.6°F)
Measurement Distance	1 to 5 cm (0.4 to 2 inches)
Memory	Last reading
Battery	2 x AAA
Fever Alarm	Yes
Weight	Approx. 100g (without batteries)
