ASSEMBLY PROCEDURES
8
Handle assembly
Note: Ensure the control cable is not twisted,
pinched or damaged when assembling
the dual fold handle.
3.
5.
6.
3. Thread one of the nuts onto the top of the bolt
and tighten with fingers. Then torque the nut
to 17 - 22 Nm Maximum.
4. Repeat steps 1 & 3 on the right side
as shown.
5. Attach the dual fold centre handle
using the knobs and bolts provided.
The knobs should be on the outside,
as shown.
6. Attach the dual fold Upper handle
using the knobs and bolts provided.
The knobs should be on the outside.
As shown.
Nut
/N
To Next Page
