Victa TORNADO EDGER TE250 User Manual

ASSEMBLY PROCEDURES
7
Your Edger should include a kit with the following parts.
When folding or unfolding the handles, ensure that the bale cable is
not caught, twisted, kinked or stretched!
Handle assembly
Assembling the handle
1. Insert the bolt through the hole, as shown.
The shoulder bolt should locate into the deck.
2. Lower handle in position as shown, Place one
of the saddle plates onto the protruding bolt.
x 4
x 6
x 2
x 2
Bolt
Handle
Not for
Reproduction
