Victa TORNADO EDGER TE250 User Manual

ASSEMBLY PROCEDURES
5
Unit details
1. Edger chassis
Note: The chassis is connected to the upper handle by the control cable.
DO NOT DISCONNECT OR CHANGE THE CABLE SCREWS!
2. Lower handle x 1
3. Centre handle x 1
4. Fastener pack
- knobs & nut x 4
- knobs & bolt x 2
- M8 square neck bolt x 6
- Saddle plates x 2
- M8 nut x 2
- M8 washers x 2
5. Front roller x 1
6. Rear wheel x 1
.BOVBM/PUTIPXOY
2
3
5
6
1
4
x 2
x 4
x 6
x 2
x 2
x 2
Not for
Reproduction
