What to do if GAS LED is OFF, and FAULT and MIN pressure indicators are flashing on my Victor Cutter?
If the GAS LED is OFF, and the FAULT and MIN pressure indicators are flashing, check if the gas supply is connected and turned on. Ensure the gas supply inlet pressure is set to 120 psi. Also, check the AIR PRESSURE CONTROL regulator setting, and adjust it as needed.
What to do if FAULT and 75 PSI indicators are flashing on my Victor Cutmaster 20mm Cutter?
If the FAULT and 75 PSI indicators are flashing, the start signal might be active when the ON/OFF switch is turned on. This can happen if the hand torch switch or hand pendant switch is held closed, or if the CNC START signal is active low. Try releasing the START signal source.
What to do if the ON/OFF Switch is ON but the A/C Indicator does not light on my Victor Cutter?
If the ON/OFF switch is ON but the A/C Indicator doesn't light, first ensure the primary power disconnect is in the ON position. Then, have a qualified person check the primary fuses/breakers. If they are fine, connect the unit to a known good primary power receptacle. If the issue persists, the unit's internal fuse may be blown and needs replacement.
Why TEMPERATURE indicator is ON and FAULT indicator is flashing on my Victor Cutmaster 20mm Cutter?
If the TEMPERATURE indicator is ON and the FAULT indicator is flashing, it could be due to obstructed airflow through or around the unit. Refer to clearance information in section 2.04. Alternatively, the unit's duty cycle might have been exceeded; in this case, allow the unit to cool.
What to do if FAULT and 70 PSI indicators are flashing on my Victor Cutmaster 20mm?
If the FAULT and 70 PSI indicators are flashing, ensure the shield cup is snug by hand-tightening it. Also, verify that the torch ATC is securely fastened to the unit.
What to do if Fault indicator and 65 PSI indicator are flashing on my Victor Cutmaster 20mm?
If the Fault indicator and 65 PSI indicator are flashing, check for proper primary input voltage. Have a qualified person check the primary voltage to ensure it meets the unit requirements, as detailed in section 2.05.
Explains the manual's symbols for notes, cautions, and warnings.
Covers hazards related to gases, fumes, electric shock, fire, and noise.
Details compliance with EU directives and standards for the equipment.
Outlines the terms, conditions, and limitations of the manufacturer's warranty.
Guides users on manual structure, symbols, and obtaining copies.
Provides technical details on input power, output current, duty cycle, and dimensions.
Details voltage, frequency, and cable requirements for system wiring.
Describes torch types, available leads lengths, and basic parts.
Explains plasma gas dynamics, pilot arc, and main cutting arc.
Step-by-step guide for connecting the primary input power to the unit.
Instructions for connecting compressed air or high-pressure cylinders.
Procedures for connecting the torch to the power supply and checking air quality.
Instructions for mounting and aligning the mechanized torch.
Identifies and describes the functions of all front panel controls and indicators.
Outlines essential pre-operation checks and settings for safe and effective use.
Guides users on selecting and changing torch parts based on operation type.
Details procedures for standoff cutting and drag cutting with a hand torch.
Covers cutting and piercing operations using the mechanized torch.
Provides tables with recommended speeds for various materials and conditions.
Outlines a schedule for routine checks and cleaning of the system.
Lists common problems, their causes, and recommended solutions.
Basic procedures for replacing power supply components like covers and filters.
Step-by-step guide for inspecting and replacing torch consumables.
Lists available optional kits, filters, and interface cables.
Details consumable parts for the SL60 torch, including tips and shields.
Provides a block diagram illustrating the operational sequence of the plasma cutter.
Illustrates wiring diagrams for hand and mechanized torch connections.
Presents the electrical schematic for the 380/400/415V units.
General| Output Current | 20A |
|---|---|
| Protection Class | IP23S |
| Cutting Capacity (Recommended) | 20 mm |
| Cutting Capacity (Maximum) | 25 mm |
| Weight | 27 kg |
| Power Source | Electric |
| Frequency | 50/60 Hz |
| Open Circuit Voltage | 300 VDC |
