Victoria Arduino Eagle One User Manual

101
FR
11.6
SCHÉMA ELECTRIQUE
EAGLE ONE 2-3 GROUPES
LUMIÈRES DES GROUPES
GL1 Groupe 1 led gauche
GR1 Groupe 1 led droit
GL2 Groupe 2 led gauche
GR2 Groupe 2 led droit
GL3 Groupe 3 led gauche
GR3 Groupe 3 led droit
RS Bande led arrière
EN
11.6
ELECTRICAL DIAGRAM
EAGLE ONE 2-3 GROUPS
GROUPS LIGHTS
GL1 Unit 1 LED left
GR1 Unit 1 LED right
GL2 Unit 2 LED left
GR2 Unit 2 LED right
GL3 Unit 3 LED left
GR3 Unit 3 LED right
RS Rear LED strip
IT
11.6
SCHEMA ELETTRICO
EAGLE ONE 2-3 GRUPPI
LUCI GRUPPI
GL1 Gruppo 1 led sinistro
GR1 Gruppo 1 led destro
GL2 Gruppo 2 led sinistro
GR2 Gruppo 2 led destro
GL3 Gruppo 3 led sinistro
GR3 Gruppo 3 led destro
RS Striscia led posteriore

Victoria Arduino Eagle One Specifications

General

Group Heads	2 or 3
Voltage	220-240 V
Water Source	Plumbed
Type	Espresso Machine
Manufacturer	Victoria Arduino
Boiler Material	Stainless Steel
Pump Type	Rotary
Pump Pressure	9 bar
Water Tank Capacity	N/A (plumbed)
Frequency	50/60 Hz
Material	Stainless Steel
Color Options	Black, White
Features	Energy Saving System
