Victoria Arduino Eagle One User Manual

99
FR
11.5
SCHÉMA ELECTRIQUE
EAGLE ONE 2-3 GROUPES
EASYCREAM
M Moteur
R Relais
RTD Capteur de température EASYCREAM
LC Compresseur gauche
RC Compresseur droit
LA Air gauche
RA Air droit
LE EASYCREAM gauche
RE EASYCREAM droit
EN
11.5
ELECTRICAL DIAGRAM
EAGLE ONE 2-3 GROUPS
EASYCREAM
M Motor
R Relay
RTD EASYCREAM temperature probe
LC Compressor left
RC Compressor right
LA Air left
RA Air right
LE EASYCREAM left
RE EASYCREAM right
IT
11.5
SCHEMA ELETTRICO
EAGLE ONE 2-3 GRUPPI
EASYCREAM
M Motore
R Relè
RTD Sonda temperatura EASYCREAM
LC Compressore sinistro
RC Compressore destro
LA Aria sinistra
RA Aria destra
LE EASYCREAM sinistro
RE EASYCREAM destro

Victoria Arduino Eagle One Specifications

General

Group Heads	2 or 3
Voltage	220-240 V
Water Source	Plumbed
Type	Espresso Machine
Manufacturer	Victoria Arduino
Boiler Material	Stainless Steel
Pump Type	Rotary
Pump Pressure	9 bar
Water Tank Capacity	N/A (plumbed)
Frequency	50/60 Hz
Material	Stainless Steel
Color Options	Black, White
Features	Energy Saving System
