Victory BX52S User Manual

37
PARTS LIST
No
Part No.
Name & Specification
QTY
1
03.02.6182.M12
locking nut M12
18
2
02.BX52.00.002
support feet
4
3
03.01.5782.M12x70
hexagon head bolt M12x35
8
4
02.BX72.04.025
lock
4
5
02.BX72.04.026
chain
2
6
03.01.77.M6x20
Hexagon socket set screws with falt point M6x20
4
7
03.05.7809.UCF210
inserted bearing with housing UCF210, without cover
1
8
02.BX52.01.008
PTO cover bracket
1
9
03.02.6182.M8
locking nut M8
10
10
02.EF.00.110
PTO cover
1
11
03.01.5782.M8x20
hexagon head bolt M8x20
10
12
03.01.5782.M14x1.5x35
hexagon head bolt M14x1.5x35
8
13
03.03.96,1.Φ14
spring washer Φ14
8
14
03.15.7940.M8x1
grease nipple M8x1
2
15
02.EFME.00.010
lower hitch bushing
2
16
03.07.DIN11023.Φ56
linch pin
3
17
02.BX52.01.017
main frame
1
18
02.EFME.00.002
upper pin
1
19
02.BX52.00.019
branch broker
1
20
03.03.97,1.Φ12
flat washer Φ12
3
21
03.01.5782.M12x35
hexagon head bolt M12x35
9
22
02.BX52.01.022
rotor shaft
1
23
03.02.6182.M14
locking nut M14
4
24
03.01.70,3.M14x50
hexagon socket countersunk head cap screws M14x50,
10.9 level
4
25
02.BX52.01.025
steel ball locker 12x50
1
26
03.05.7809.UCF210
inserted bearing with housing UCF210, with cover
1
27
03.02.6182.M10
locking nut M10
19
28
02.BX52.00.028
rotor knife
4
29
03.01.70,3.M10x35
hexagon socket countersunk head cap screws M10x35,
10.9 level
16
30
02.BX52.01.030
counter knife
1
31
03.01.798.M12x60
eyelet bolt M12x60
2
32
03..02.6170.M12
common nut M12
4
33
03.01.5782.M10x70
hexagon head bolt M10x70
2
34
03.01.5782.M10x35
hexagon head bolt M10x35
1
35
03.03.97,1.Φ10
flat washer Φ10
20
36
02.BX52.01.036
rotor
1
37
03.01.5782.M12x160
hexagon head bolt M12x160
1
38
02.BX52.00.038
upper housing
1
39
03.01.5782.M6x30
hexagon head bolt M6x30
4
40
03.02.6182.M6
locking nut M6
6
41
02.BX52.00.41
plate 1
1
42
02.BX52.00.42
plate 2
1
43
02.BX52.00.043
output chute
1
