User Manual for FSA Freezers Victory
Rev. 10/20 Victory 7
CLEARANCE AND PLACEMENT
Placement
Consider the following when selecting a location for your Freezer:
Clearance:
• 12 in. at the top
• 0.0 in. at the rear,
• 0.0 in. at the left side
• 0.0 in. at the right side
Floor Load: the oor on which the Freezer is located must be even and level, free from vibrations, and strong enough to
support the combined weights of the unit and maximum product load.
Ventilation: Grille area at front must be free and clear of any object or wall.
Power Outlet: Dedicated power outlet is located within the length of the unit's power cord.
0" AT SIDES
0" AT
FLOOR
12" AT TOP
0" AT
REAR
